Cabinet Type Air-conditioner Indoor Unit Motor

YDK series Motor

Model No.

Power(W)

Voltage(V)

Frequency(HZ)
Speed regulating
Number of  poles

Noise(db)
YDK-35-8E
35
200-240
50
123
8
40
YDK-40-8E
40
200-240
50
123
8
40
YDK-50-8E
50
200-240
50
123
8
40
YDK-65-8E
65
200-240
50
123
8
40
YDK-70-8E
70
200-240
50
123
8
40
YDK-80-8E
80
200-240
50
123
8
40

Dimension & mounting Size:

142 Iron-cored Steel-clad Motor

NOTES 1.        THIS MOTOR MEETS CCEE SPECIFICATION (CHINESE NATIONAL STANDARD).     2.        OEM TECHNICAL PARAMETER FROM CLIENT TO MAKE SIMILAR TYPE OF MOTOR IS WELCOME. 3.        THE CHARACTER OF THIS MOTOR:         l       THE SHELL OF THIS MOTOR IS WELDED INTO SHAPE WITH MATERIAL OF STAINLESS         STEEL PLATE.     l       THE MATERIAL OF ALUMINIUM-ALLOY IS CAST IN THE SHAPE OF TOP-END.         l       THE STATOR WINDING IS IN 8 POLES.     l       THE IMPORTED LOW NOISE BALL BEARING     l       IT IS THE IDEALEST MOTOR HOME AND ABROAD WITH THE CHARACTER OF LOW         ROTATION, STRONG WIND AND VERY LOW NOISE. 4.        THIS MOTOR ASSEMBLY IS TOP COATED WITH ANTIRUST PAINT IN GOOD FINISH. AND THE     INNER OF THE TOP-END IS COATED WITH ANTIRUST PAINT, TOO. 5.        ZINC/DICHROMATE PLATED HARDWARE IS THROUGHOUT.     6.        STATOR IS COATED WITH BLACK WATER PAINT.    7.        ROTATOR SURFACE IS COATED WITH RUST INHIBITOR.     8.        THERMOSTATIC PROTETOR IS ASSEMBLIED IN THIS MOTOR.     9.        MOTOR CONNECTION LEADS IS ATTACHED TO PVC FLEXIBLE WIRE RV105 IN UL APPROVAL. 10.     THIS MOTOR IS APPLICABLE TO CABINET TYPE AIR CONDITIONER INDOOR UNIT 2PH, 3PH,      5PH.
